Edge Capacity Gate

If you only open one file, open START_HERE.md.

Edge Capacity Gate evaluates RAM, disk, and thermal before dispatching Playwright / spawn-worker / deep-research, and returns STATUS: CAPACITY_PRESSURE instead of crashing the inference process.

On Jetson-class and laptop agents, the heavy tool and the LLM share one box. LangGraph can hide tools from the next model call; LiteLLM caps USD. Neither stops this turn’s browser from eating the KV cache. Missing psutil is not 0% RAM.

Suggested GitHub / PyPI name: edge-capacity-gate

Who it helps

Who	What they get
You (the technician)	evaluate_capacity + should_block_heavy in ten minutes.
AI agents / harnesses	A STATUS / WHY / USE_INSTEAD packet as the tool result, plus a cheap inspect tool still visible.
People talking to those agents	Fewer OOM killer events and fewer sitrep storms from the same deny.

Who should skip this

Cloud agents whose browser runs on a different machine from the LLM. Teams that already fail-closed when RAM sensors are missing and dedupe operator pages. People looking for a USD budgeter — that is LiteLLM.

How it connects to AI agents

flowchart LR
  C[Tool call] --> H{heavy?}
  H -->|no| R[Run cheap tool]
  H -->|yes| E[evaluate_capacity]
  E -->|pressure| P[STATUS CAPACITY_PRESSURE]
  E -->|headroom| T[Dispatch Playwright]
  P --> D{dedupe window?}
  D -->|fresh| S[one sitrep]
  D -->|recent| N[packet only]

Loading

Style	When
In-process (recommended)	Call should_block_heavy before tool_registry[name](**args).
Harness	Hide playwright_* when pressure is true; keep inspect_system_health.
Both	Dispatcher returns the packet; the chat model only reads it.

This kernel has no MCP server. Pair epistemic-deny for allowlist packets (same family, different STATUS) and agent-review-envelope if you enqueue a sitrep (optional; needs that sibling on PYTHONPATH).

10-minute first success

chmod +x scripts/smoke.sh
./scripts/smoke.sh
# optional
export AGENT_HOME=/tmp/edge-capacity-gate-demo
python3 -m pip install -e ".[sensors]"
python3 examples/quickstart.py

Success is a printed snapshot whose memory_sensor is ok or missing (never a fake memory_percent=0.0 when the sensor is gone) and, under pressure, a packet that starts with STATUS: CAPACITY_PRESSURE and includes USE_INSTEAD:. Two denies inside 900s must not enqueue two sitreps. That rigidity is the product.

Hardware / software

Resource	Minimum
OS	Linux, macOS, or Windows with Python 3.10+
RAM	This kernel is for hosts where the LLM and browser share RAM
GPU	None required for the library; local inference is the reason it exists
Network	None

Optional extra: psutil (pip install -e ".[sensors]"). Without it, memory_sensor=missing and heavy tools are refused — not treated as 0% used. Thermal JSON is optional; missing is UNKNOWN, not NORMAL.

Repository layout

File	What it does	What you change it for
START_HERE.md	First-use, 10 minutes	You usually do not
README.md	Product + hidden dynamics	Forks / rename
docs/INTEGRATION.md	Dispatcher + harness recipes	Tool names
docs/ADVANCED.md	Playwright OOM vs budgeters (search article)	Architecture debates
capacity_gate.py	Evaluate / deny / dedupe	Thresholds, heavy list
paths.py	AGENT_HOME stub	Rarely
examples/quickstart.py	First snapshot	Learning
tests/	Missing sensor ≠ 0%; packet; dedupe	Behavior changes
scripts/smoke.sh	unittest + quickstart	CI locally
.env.example	Env names	Copy to .env (never commit .env)

Related kernels

Kernel	Why
epistemic-deny	Allowlist packets. Capacity is not a permission miss — same shape, different STATUS.
agent-review-envelope	Speech dual-control. Capacity sitreps belong in the outbox, once per window.
sidecar-occupancy	HTTP 503 is a lock. This kernel is RAM/thermal, not a sidecar mutex.
Curiosity-Docker	House-style START_HERE; not a capacity gate.

What others will discover (that demos hide)

These dynamics show up after someone else runs this in a real loop. Ordinary READMEs skip them; they are why the kernel exists.

Lens	In this kernel
Hidden principle	A missing occupancy sensor must not look like 0% used (or NORMAL thermal). Mapping None → 0.0 fail-opens the gate forever.
Recurring pattern	Deny heavy tools before dispatch. Same packet family as epistemic denies (STATUS / WHY / USE_INSTEAD). Dedupe sitreps with a wall-clock marker.
Mental model	Adopters think “psutil percent is a float, default 0.” The governing model is unknown ≠ free. LangGraph post_model_hook is a conversation guardrail, not a RAM budget. LiteLLM max_budget is USD.
Feedback loop	No dedupe → every denied Playwright pages the human → model retries → sitrep storm → operators stop having an opinion (per Cynical0n3 NotebookLM systems).
Hidden incentive	The model wants to “just screenshot.” The box wants to keep the KV cache. They share DRAM. Cheap to skip the pre-check “just this once.”
Leverage point	pressure_dedupe_seconds (default 900). memory_sensor / thermal_sensor fields. Hide playwright_* when pressure; keep a cheap inspect tool.
Asymmetry	RAM unknown → refuse heavy tools. Thermal JSON missing → UNKNOWN (visible) and only blocks if you list it in block_heavy_when_thermal. Do not copy the RAM rule onto optional thermals without meaning to.
Cause → effect	Browser + local LLM on one box without a pre-check → OOM killer / paging “slow as molasses.” Packet → model uses inspect tools. Marker → one sitrep per window.
Second-order	Once copied, teams will chart “deny rate” and raise memory_percent_max or stub psutil to return 0 so the demo never blocks. That metric is the next OOM. Count OOM events and sitreps per hour, not denials.
Opportunity	Edge / ARM / laptop agents. Search: Playwright OOM local LLM.
Risk if copied blindly	Enqueue on every deny without the marker file. Treat missing psutil as 0%. Add an MCP tool that bypasses the gate.

Deeper case studies: docs/ADVANCED.md. Wiring: docs/INTEGRATION.md.

License

MIT. See LICENSE.
